Yidaneng 10kw 12.5kva natural gas turbine generator set for sale

FOB Reference Price:Get Latest Price
US $20,000-50,000 / Sets | 1 Set/Sets Yidaneng 10kw 12.5kva natural gas turbine generator set for sale (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Yidaneng
Model Number:
YDNG-10
Output Type:
AC Three Phase
Speed:
1500/1800rpm
Frequency:
50/60HZ
Rated Power:
10kw/12.5kva
Rated Voltage:
230/400V 380/220V
Rated Current:
18~900A
Product name:
Yidaneng 10kw 12.5kva natural gas turbine generator set for sale
Color:
As your requirement
Test:
8 hours testing time
Gas consumption:
0.33cbm/kwh
Function:
ATS / AMF
Warranty:
One or 1500 running hours
Fuel:
Gas
Connection Type:
3Phase 4Wire
Cooling system:
Water cooled
Control Panel:
Digital and visible
SupplyAbility
SupplyAbility:
100 Set/Sets per Month Yidaneng 10kw 12.5kva natural gas turbine generator set for sale
Packaging & Delivery
Packaging Details
In plywood case or standard packing,Yidaneng 10kw 12.5kva natural gas turbine generator set for sale
Port
Qingdao
Lead Time :
20-40 workdays after your deposit

Yidaneng 10kw 12.5kva natural gas turbine generator set for sale

Product Description

product description.jpg



1.

Natural gas generator widely used to the oil fields, coal mines, chemical industry, carbon industry, wine factories, ferment factories, and food processing, rubbish burying factories, waste water processing factories.

2.

Natural gas methane and other gas can be used as the fuel for Gas Genset. This equipment can be applied into transformation of railway and high way at low running cost. It can also be widely popularized in farms, paddy crust, and saw waste can be the materials to generator electricity.

Specification:

  1. It makes the high efficiency and compact space with great transmission;

  2. It's safe and stable for electrical system with structure; low consumption.

  3. With advanced technology: good  quality, great power, running stability.

  4. Choosing famous brands 100% copper brushless alternator. Power Efficiency :90%; Insulation Class: H

Techinical data:



Genset

Prime Power

Speed

Current

Cooling method

Start method

Governor

Engine model

Model

KW

KVA

(rpm)

(A)

GH-10GFZ

10

13

1500

18

closed water cooled

Electric

ESC

YD480

GH-20GFZ

18

23

1500

36

closed water cooled

Electric

ESC

4100Q

GH-30GFZ

30

38

1500

54

closed water cooled

Electric

ESC

4105Q

GH-50GFZ

50

63

1500

90

closed water cooled

Electric

ESC

6105Q

GH-75GFZ

75

94

1500

135

closed water cooled

Electric

ESC

WD615Q

GH-100GFZ

100

125

1500

180

closed water cooled

Electric

ESC

6140Q

GH-120GFZ

120

150

1500

217

closed water cooled

Electric

ESC

6140Q

GH-120GFZ

120

150

1500

217

closed water cooled

Electric

ESC

WD615ZQ

GH-150GFZ

150

188

1500

270

closed water cooled

Electric

ESC

12V135Q

GH-200GFZ

200

250

1500

361

closed water cooled

Electric

ESC

12V138Q

GH-250GFZ

250

313

1500

450

closed water cooled

Electric

ESC

12V135ZQ

GH-275GFZ

275

344

1500

495

closed water cooled

Electric

ESC

12V138ZQ

GH-500GFZ

500

625

1500

900

closed water cooled

Electric

ESC

12V190ZQ

More details:

Rated Voltage

400/230V(adjustable)

Connecting Type

3 phase, 4 wires

Power Factor

0.8 (lagging)

Protection Grade

IP21/23

Insulation Class

H/H

Voltage Regulation

≥±5%

Voltage Regulation, Stead State

≤±1%

Sudden Voltage Warp (Sudden Reduce)

≤+20%

Sudden Voltage Warp (Sudden Increase)

≤-15%

Voltage Stable Time ( Sudden Reduce)

≤1.0S

Voltage Stable Time (Sudden Increase)

≤1.0S

Frequency Regulation, Stead State

≤0.5%

Frequency Waving

≤0.5%

Frequency Recovery Time ( Sudden Reduce)

≤1.0S

Frequency Recovery Time (Sudden Increase)

≤1.0S

















































Specifications:

1) Rated power from 10kw-500kw

2) Power by famous and good quality gas engine and alternator

3) Longer life: natural gas engine has a life of over several years if it is properly

    operated and maintained

4) Low operation cost: natural gas has a rich reserve with low cost and a high

    rate of return

5) High profit: low operation cost, supply of electricity and thermal power at the

    same time, low maintenance cost

6) Coupled with brushless alternators of Leroy Somer / Engga

7) Well performed control system, high quality monitor instrument, with sound

    and light alarm devices, auto shutdown

8) Protection function: over-current, under-voltage, auto-regulate voltage,

    reverse power

9) Monitor function: speed, water temperature, lube-oil temperature, lube-oil

    pressure, exhaust temperature

10) Gas consumption: less than 0.33cbm/kWh

11) Supply connection: 3 phase, 4 lines

12) Rated voltage: 400V

13) Rated speed: 1,500rpm/1,800rpm

14) Rated frequency: 50Hz / 60Hz

15) Rated power factor: 0.8

16) Exciting way: brushless

17) Starting mode: 24V DC electric starting system

18) Cooling mode: closed-circuit cooling system

Product Display

product display.jpg

 CNG biogas yangdong (1)CNG biogas yangdong (3)CNG biogas yangdong (4)CNG biogas yangdong (2)

Product Advantages

Spare Part Advantages
1. Generator adopts 100% copper brushless alternator.
2. With good quality fuel tank.
3. Kinds soundproof, weatherproof, canopy choice.
4. Automatic control and automatic transfer switch.
5. All spare parts are versatility and easy maintenance.
Company Information
-1_01.jpg-2.jpgbusiness partner.jpgcertification packing.jpgwhiy choose us1.jpgwhy choose us2.jpg



FAQ

1. How can I get the details quotation ?
Please tell us the specification of the units you need. For example, Genset power, Engine model, Prime power, Engine brand, Control system, Soundproof Canopy, Trailer Automatic transfer switch as much as you can. Our expert engineers offer technical consultation and assort guidance.
2. How often do I need to maintenance my generator?
Firstly, we will provide you with high performance products installation, design or material and quick repairment. To ensure the units running stability we will make user manual to write down every part maintenance period.
3. How can I make my generator 'automatic'?
It depends on your choice. We can make any generator installation automatic. We will install automatic transfer switch to achieve your need. ATS can automatically transfer load between the main power and the emergency without operator.
4. What is the warranty period?
One year or 1500 running hours, whichever comes first.
5. What kind of certificate can you offer?
ISO9001, CE
6.What kind of package do you use in delivery?
- Less than whole container cargo, playwood case, whole container cargo, naked packing.
7. Can you customize the genset?

You are hot welcomed to contact us! Not exactly what you want? 1 request, multiple quotations.
