Weifang ricardo 50kva 40kw diesel generator price

FOB Reference Price:Get Latest Price
US $1,000-6,000 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
400 Set/Sets per Month
Port:
Qingdao China 40kw ricardo diesel generator 50kva diesel generator
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
YIDANENG
Model Number:
YDNW-40
Output Type:
AC Three Phase
Speed:
1500/1800rpm
Frequency:
50/60HZ 50kva generator
Rated Power:
12.8kw 40kw ricardo diesel engine
Rated Voltage:
230/400V40kw ricardo diesel generator
Rated Current:
72A 50kva ricardo diesel generator
Name:
Weifang ricardo 50kva 40kw diesel generator price
Connection Type:
3Phase 4Wire
Color:
Customers' Requirement
Diesel generator Usage:
Prime/stanby
Protection Grade:
IP23
Cooling system:
Water cooled
Function:
AMF,ATS
Control Panel:
Digital and visible
Altermator:
Stamford or copy Stamford
generator price Colour:
As your requirement
Packaging & Delivery
Packaging Details
In plywood case or standard packing,Weifang 40kw/50kva ricardo diesel generator for sale,40kw/50kva ricado diesel generator,50kva generator,50kva ricardo diesel generator
Delivery Time
With 15-30 days after the order 40kw diesel generator

Weifang ricardo 50kva 40kw diesel generator price

Product Description



Diesel Generator Brands:
Weifang Ricardo diesel generator choose the domestic famous brand Ricardo series diesel engine as dynamic force which adopts advanced technology.
With the importing of technology of Ricardo Company power from 6.6ke to 500kw.
Weifang Ricardo diesel generator adopted 100% cooper brushless alternator brand.
Containing with 8-24 hours fuel tank, automatic transfer switch, and adopting water cooling technology for keeping running efficiency.
Weifang Ricardo diesel generator set is widely used as major or back up tower supply in fieldwork, high building, supermarket, factory, oilfield, high road, harbor countryside and so on.

Specification:

  1. With the jacketed high-pressure fuel pipe, it is safe and reliable;

  2. It makes the high efficiency and compact space with great transmission;

  3. It's safe and stable for electrical system with structure; low consumption.

  4. With advanced technology: good  quality, great power, running stability.

  5. Choosing famous brands 100% copper brushless alternator. Power Efficiency :90%; Insulation Class: H

1. Specification of genset

Genset Model

YDNW-40

Rated Frequency

50HZ

Power Factor

0.8

Rated Voltage

400/230V

Rated Power (KW/KVA)

40/50

Standby Power (KW/KVA)

44/55

Phase/Wire

3Phase, 4Wire

Overall Size (mm)

1850×750×1200

Weight (kg)

810

2. Specification of diesel engine

Model

4105D

Type

Water-cooled, in-line, 4-stroke, direct injection,
wet cylinder liner, 1500rpm

Rated Power (kw)

44

Intake Type

Natural

No. of Cylinder

4.L

Bore×Stroke (mm)

105×125

Piston Speed (m/s)

6.25

Compression Ratio

17:01:00

Mechanical Governor Rated

≤5%

Electronical Governor Rated

≤1%

Noise Level (dBA)

≤96

Exhaust Temperature ()

600

Lube Oil Capacity (L)

12

Rated Fuel Consumption (L/h)

11.55

Displacement (L)

4.33

3. Specification of alternator

Model

TFW2-40

Rated Power (KW/KVA)

40/50

Power Efficiency

87%

Voltage Regulation

≤±1

Excitation Type

Brushless

Insulation Class

H

4. Specification of control system

Model

Smartgen6110

Working Voltage

DC8.0V to DC35.0V, continuous

Overall Dimensions

197 mm x 152 mm x 47mm

Panel Cutout

186mm x 141mm

Working Condition

Temperature: (-25~70)ºC; Humidity: (20~90)%

Weight

0.56kg



Product Display

Product Advantages

Spare Part Advantages

1. 6.5kw to 500 kw Ricardo diesel generator adopts 100% copper brushless alternator.

2. With good quality fuel tank.

3. Kinds soundproof, weatherproof, canopy choice.

4. Automatic control and automatic transfer switch.

5. All spare parts are versatility and easy maintenance.







The advantages of 6.5kw to 500kw diesel generator

6.5kw to 500kw ricardo diesel engine generator  adopts advanced technology. Featured with good economic performance, compact structure, great power, easy- operation.

The engine of ricardo diesel engine generator is in low fuel consumption rate and low emission, good dynamic performance, small volume, compact structure, great power, running stability, easy-operation, safety and reliable.

6.5kw to 500kw ricardo diesel engine generator adopts advanced design and reliable performance. The material of engine adopts moisture proof and derusting processing, protecting the gen set from humid weather.

With the jacketed high-pressure fuel pipe for good atomization and combustion.
